Commands listed in alphabetical order
Group
Cursor
Syntax
DISplay:WAVEView<x>:CURSor :CURSOR<x>:SPLITMODE {SAM E|SPLIT}
DISplay:WAVEView<x>:CURSor :CURSOR<x>:SPLITMODE?
Arguments
SAME species both cursors have the same source.
SPLIT species the cursors have different sources.
Examples
DISplay:WAVEView1:CURSor:C URSOR1:SPLITMODE SPLIT species the
cursors have different sources.
DISplay:WAVEView1:CURSor:C URSOR1:SPLITMODE? might return
:DISPLAY:WAVEVIEW1:CURSOR: CURSOR1:SPLITMODE SAME indicating the
cursors have the same source.
DISplay:WAVEView<x>:CURSor:CURSOR<x>:STATE
This command sets or queries the visible state of the specied cursor in the
specied waveview.
NOTE.
WAVEView<x >
is the specied waveview and must be
WAVEView1
.
Cursor<x>
is the specied cursor and must be
CURSOR1
.
Group
Cursor
Syntax
DISplay:WAVEView<x>:CURSor :CURSOR<x>:STATE {<NR1>|O FF|ON}
DISplay:WAVEView<x>
:CURSor:CURSOR<x>:STATE?
Arguments
<NR1> = 0 disables the specied cursor in the specied waveview; any other
value turns this feature on.
OFF disables the specied cursor in the specied waveview.
ON enables the specied cursor in the specied waveview.
Examples
DISplay:WAVEView1:CURSor:C URSOR1:STATE OFF turns the specied
cursor off.
DISplay:WAVEView1:CURSor:C URSOR1:STATE? might return
:DISPLAY:WAVEVIEW1:CURSOR: CURSOR1:STATE 1 indicating the specied
cursor in the specied waveview is on.
MSO54, MSO56, MSO58, MSO58LP Programmer 2-297
