Commands listed in alphabetical order

Arguments

<QString> is th

e label value.

Examples

TRIGGER:A:BUS:B1:ARINC429A :SDI:VALUE "X0" sets the value to X0.

TRIGGER:A:BUS:B1:ARINC429A :SDI:VALUE? might return "XX", indicating

that the value is XX.

TRIGger:{A|B}:BUS:B<x>:ARINC429A:SSM:VALue

This command sets or queries the label value when triggering on an ARINC429

SSM ﬁeld. The bus number is speciﬁed by x. The trigger condition must be

set to DATa or LABELANDDATA, and the data format must be set to DATA

or SDIDATA.

Conditions

Requires the SR-AERO Triggering and Analysis application.

Group

Trigger

Syntax

TRIGger:{A|B}:BUS:B<x>:ARI NC429A:SSM:VALue <QString>

TRIGger:{A|B}:BUS:B<x>:ARI NC429A:SSM:VALue?

Arguments

<QString> is the label value.

NOTE. The SSM ﬁeld is only present when the selected data ﬁeld format is DATA

or SDIDATA (using

BUS:B<x>:ARI NC429A:DATAFORmat

). Also, the stored

QString is reset to its default value whenever the data ﬁeld format is changed.

Examples

TRIGGER:A:BUS:B1:ARINC429A :SSM:VALUE "X0" sets the value to X0.

TRIGGER:A:BUS:B1:ARINC429A :SSM:VALUE? might return "XX", indicating

that the value is XX.

TRIGger:{A|B}:BUS:B<x>:AUDio:CONDition

This command sets the condition (word select, start of frame, or m atching data)

to be used when triggering on an audio bus signal. The bus number is speciﬁed

by <x>.

Conditions

Requires the SR-AUDIO Triggering and Analysis application.

MSO54, MSO56, MSO58, MSO58LP Programmer 2-765
