Command groups
Table 2-37: Search and Mark commands (cont.)
Command
Description
SEARCH:SEARCH<x>:TRIGger:A:STATE Sets or queries the enabled state of the search.
SEARCH:SEARCH<x>:TRIGger:A:STOPAcq Sets or queries whether acquisitions are stopped when a search hit is found.
SEARCH:SEARCH<x>:TRIGger:A:TIMEOut:
LOGICQUALification
Sets whether or not to use logic qualification for a timeout search.
SEARCH:SEARCH<x>:TRIGger:A:TIMEOut:
POLarity
Sets or queries the polarity to be used for a Timeout search.
SEARCH:SEARCH<x>:TRIGger:A:TIMEOut:
SOUrce
Sets and queries the source for timeout search input.
SEARCH:SEARCH<x>:TRIGger:A:TIMEOut:
THReshold
Sets or queries the source threshold level for a timeout trigger search to determine
wheretoplaceamark.
SEARCH:SEARCH<x>:TRIGger:A:
TRANsition:LOGICQUALification
Specifies whether or not to use logic qualification for a transition search.
SEARCH:SEARCH<x>:TRIGger:A:
TRANsition:POLarity
Specifies the polarity for the transition search.
SEARCH:SEARCH<x>:TRIGger:A:
TRANsition:SOUrce
Sets and queries the source for the transition search input.
SEARCH:SEARCH<x>:TRIGger:A:
TRANsition:THReshold:HIGH
Sets or queries the source threshold HIG H level for a transition trigger search to
determine where to place a mark.
SEARCH:SEARCH<x>:TRIGger:A:
TRANsition:THReshold:LOW
Sets or queries the source threshold LOW level for a transition trigger search to
determine where to place a mark.
SEARCH:SEARCH<x>:TRIGger:A:WINdow:
CROSSIng
Sets or queries the window trigger threshold crossing of the selected trigger Source.
SEARCH:SEARCH<x>:TRIGger:A:WINdow:
LOGICQUALification
Specifies or queries whether or not to use logic qualification for a window search.
SEARCH:SEARCH<x>:TRIGger:A:WINdow:
POLarity
Sets or queries the window trigger threshold crossing of the selected trigger Source.
SEARCH:SEARCH<x>:TRIGger:A:WINdow:
SOUrce
Sets and queries the source for the window search input.
SEARCH:SEARCH<x>:TRIGger:A:WINdow:
THReshold:HIGH
Sets or queries the source threshold HIG H level for a transition trigger search to
determine where to place a mark.
SEARCH:SEARCH<x>:TRIGger:A:WINdow:
THReshold:LOW
Sets or queries the source threshold LOW level for a transition trigger search to
determine where to place a mark.
SEARCH:SEARCH<x>:TRIGger:A:WINdow:
WHEn
Sets or queries the window search event.
SEARCH:SELected Sets or queries the selected search.
MSO54, MSO56, MSO58, MSO58LP Programmer 2-73
