Benelli TNT125 Service Manual

●MT05 Fault Code Table
Remark:
All fault display functions of Delphi are listed in
the fault code table.
If this model does not have the
corresponding function, please ignore it)
System or
Component
DTC
Number
DTC Description Related Calibration
anifold Absolute
Pressure Sensor
(MAP)
P0107 MAP Circuit Low Voltage or Open KsDGDM_MAP_ShortLow
P0108 MAP Circuit High Voltage KsDGDM_MAP_ShortHigh
Intake
Temperature
Sensor (IAT)
P0112 IAT Circuit Low Voltage KsDGDM_IAT_ShortLow
P0113 IAT Circuit High Voltage or Open KsDGDM_IAT_ShortHigh
Coolant/Oil
Sensor
P0117
Coolant/Oil Temperature Sensor Circuit
Low Voltage
KsDGDM_CoolantShortLow
P0118
Coolant/Oil Temperature Sensor Circuit
High Voltage or Open
KsDGDM_CoolantShortHigh
Throttle Position
Sensor (TPS)
P0122
TPS Circuit Low Voltage or Open
KsDGDM_TPS_ShortLow
P0123
TPS Circuit High Voltage
KsDGDM_TPS_ShortHigh
Oxygen Sensor
P0131 O2S 1 Circuit Low Voltage KsDGDM_O2_1_ShortLow
P0132 O2S 1 Circuit High Voltage KsDGDM_O2_1_ShortHigh
Oxygen Sensor
Heater
P0031 O2S Heater Circuit High Voltage KsDGDM_O2_HeaterShortHigh
P0032 O2S Heater Circuit Low Voltage KsDGDM_O2_HeaterShortLow
Fuel Injector A
P0201
Injector A Fault
KsDGDM_INJ_CYL_A_FaultHigh
Fuel Injector B
P0202 Injector B Fault KsDGDM_INJ_CYL_B_FaultHigh
Fuel Pump Relay
(FPR)
P0230
FPR Coil Circuit Low Voltage or Open
KsDGDM_FPP_CircuitShortLow
P0232 FPR Coil Circuit High Voltage KsDGDM_FPP_CircuitShortHigh
Crankshaft
Position Sensor
(CKP)
P0336 CKP Sensor Noisy Signal KsDGDM_CrankNoisySignal
P0337 CKP Sensor No Signal KsDGDM_CrankNoSignal
Ignition Coil A
P0351
Cylinder A Ignition Coil fault
KsDGDM_EST_A_Fault
Ignition Coil B
P0352 Cylinder B Ignition Coil fault KsDGDM_EST_B_Fault
Idle Control
System
P0505 Idle Speed Control Error KsDGDM_IdleControl
System Voltage
P0562 System Voltage Low KsDGDM_SysVoltLow
P0563 System Voltage High KsDGDM_SysVoltHigh
MIL
P0650 MIL Circuit Malfunction KsDGDM_MIL_Circuit
Tachometer
P1693 Tachometer Circuit Low Voltage KsDGDM_TAC_Circuit_Low
P1694
Tachometer Circuit High Voltage
KsDGDM_TAC_Circuit_High
Oxygen Sensor 2
P0137 O2S 2 Circuit Low Voltage KsDGDM_O2_2_ShortLow
P0138
O2S 2 Circuit High Voltage
KsDGDM_O2_2_ShortHigh
Oxygen Sensor
P0038 O2S Heater 2 Circuit High Voltage KsDGDM_O2_HeaterShortHigh
