Heater 2
P0037 O2S Heater 2 Circuit Low Voltage KsDGDM_O2_HeaterShortLow
Vehicle Speed
Sensor
P0500 VSS No Signal KsDGDM_VSS_NoSignal
Park Neutral
Switch Diag
P0850 Park Neutral Switch Error KsDGDM_ParkNeutralSwitch
CCP
P0445 CCP short to high KsDGDM_CCP_CircuitShortHigh
P0444
CCP short to low/open
KsDGDM_CCP_CircuitShortLow
Rollover Sensor
Diagnostic
P1500 Rollover Sensor malfunction/Triggered KsDGDM_RolloverSensor
BLM_MaxAdapt
P0171 Several BLM value hit maximum KsFDIAG_BLM_MaxAdapt
BLM_MinAdapt
P0172 Several BLM value hit minimum KsFDIAG_BLM_MinAdapt
PESystLean
P0174
PE mode burned AFR keeps lean
KsFDIAG_PESystLean
- 178 -

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Benelli TNT125 and is the answer not in the manual?

Benelli TNT125 Specifications

General IconGeneral
Displacement125 cc
Transmission5-speed
Fuel SystemEFI
Fuel Capacity7.2 liters
Seat Height780 mm
Dry Weight116 kg
Bore x Stroke54 mm x 54.5 mm
Starting SystemElectric
Wheelbase1215 mm
Engine TypeSingle cylinder, 4-stroke, air-cooled
Front SuspensionUpside-down fork
Front BrakeSingle disc
Rear BrakeSingle disc
Front Tire120/70-12
Rear Tire130/70-12
Max Power8.2 kW (11.1 Cv) @ 9500 rpm
Rear SuspensionSwing arm with lateral shock absorber with adjustable spring preload
