Benelli TNT125 Service Manual

No. Chinese name and specifications
Torque
Remark
N·m kgf·m
1 Screw M6×23
10 1.0
2 Mounting cap
3 Front brake switch component
4 Washer φ4
5 Washer φ4
6 Screw M4×12
7 Bolt
2 0.2 G
8 Lever
9 Nut M6 6 0.6
10 Fuel pump component
11 Hexagon flange bolts
30
3.0
B
12 Seal
R
13 Brake hose assembly
14 Brake caliper (red)
15 Friction plate component
16 Inner hexagon screw M8×1.25×25 22 2.2
L
17 Front hydraulic brake component
B: apply brake fluid.
G: apply grease.
L: apply thread fastening glue.
R: replace parts.
Si: apply silicone grease.
- 310 -

Benelli TNT125 Specifications

General

Displacement	125 cc
Transmission	5-speed
Fuel System	EFI
Fuel Capacity	7.2 liters
Seat Height	780 mm
Dry Weight	116 kg
Bore x Stroke	54 mm x 54.5 mm
Starting System	Electric
Wheelbase	1215 mm
Engine Type	Single cylinder, 4-stroke, air-cooled
Front Suspension	Upside-down fork
Front Brake	Single disc
Rear Brake	Single disc
Front Tire	120/70-12
Rear Tire	130/70-12
Max Power	8.2 kW (11.1 Cv) @ 9500 rpm
Rear Suspension	Swing arm with lateral shock absorber with adjustable spring preload
