No. Chinese name and specification
Torque
Remark
N·m kgf·m
1
Frame welding component
2 Bolt M8×70 25
2.5 S
3 Bolt M10×1.25×90 50
5.0
4
Left front hanging plate of engine
5
Right front hanging plate of engine
6 Self-locking nut M8 25
2.5
AL
S
7 Self-locking nut M10×1.25 50
5.0
ALS
8 Front guard mounting base
9 Bolt M6×12 10
1.0
10 Bolt M10×1.25×110 50
5.0
11 Bolt M8×65 25
2.5
12
Upper hanging plate of engine
13
Side stand welding component
14
Side stand spring
15
Side stand mounting bolt
50
5.0
16 Nut M10×1.25 50
5.0
17 Air filter mounting seat
18 Bolt M8×1.25×30 25
2.5
ALS
19 Spring gasket 8
20 Rubber washer lining
21 Rubber ring
22 Guard rubber washer
23 Seat lock mounting base
24 Bolt M6×30 10
1.0
25 Washer
26 Guard rubber washer
27 Shaft sleeve
28 Clamp
29 Voltage regulator mounting base
30 Clutch cable clamp component
31 Frame brandname
32 Brandname rivet 3×6
33 Clutch clamp component
AL: tighten the clamp bolt twice alternately in accordance with the higher locking torque.
G: apply grease.
L: apply thread fastening glue.
R: replace parts.
S: obey the specified tightening order.
- 369 -
