Benelli TNT125 Service Manual

No. Chinese name and specification
Torque
Remark
N·m kgf·m
1 Rear fender
2 Front of rear fender
3 Screw M6×14
4 Card nut M6
5 Battery retainer component
6
Mounting seat weldin
g component of rear
upper fender
7 Screw M6×35 10
1.0
8 Washer 6
9 Spring washer 6
10 Rear upper fender collar
11 Self-tapping screw ST4.2×13
12 Rear license plate mounting plate
13 Rear license plate
14 Self-tapping screw ST4.2×10
15 Rear reflector component
16 License plate light
17 Rear lower fender
18 Bolt M6×19
19 Left connecting plate of rear lower fender
20 Right connecting plate of rear lower fender
21 Card nut M6
22 Rear lower license plate bracket
23 Screw M6×20
24 Washer φ6
25 Self-locking nut M6
26 Front reflector
27 Nut M5
28 Rear reflector
29 Rear license plate light
- 379 -

Benelli TNT125 Specifications

General

Displacement	125 cc
Transmission	5-speed
Fuel System	EFI
Fuel Capacity	7.2 liters
Seat Height	780 mm
Dry Weight	116 kg
Bore x Stroke	54 mm x 54.5 mm
Starting System	Electric
Wheelbase	1215 mm
Engine Type	Single cylinder, 4-stroke, air-cooled
Front Suspension	Upside-down fork
Front Brake	Single disc
Rear Brake	Single disc
Front Tire	120/70-12
Rear Tire	130/70-12
Max Power	8.2 kW (11.1 Cv) @ 9500 rpm
Rear Suspension	Swing arm with lateral shock absorber with adjustable spring preload
