Benelli TNT125 Service Manual

No. Chinese name and specification
Torque
Remark
N·m kgf·m
1
Left guard
2 Left guard
3 Screw M6×14
4 Card nut M6
5
Left tail cover
6
Right
tail cover
7 Connecting plate between left and right tail covers
8 Decorative cover
9 Self-tapping screw ST4.2×13
10 Decorative cover of left guard
11 Decorative cover of right guard
12 Self-tapping screw ST4.2×10
13 Left decorative plate
14 Right decorative plate
15 Inner hexagon screw M6×14
16 Front seat component
17 Rear seat component
18 Bolt M6×19
19 Collar
20 Taillight
21 Screw M6×12
22 Rear left turn signal light
23 Rear right turn signal light
24 Inner hexagon screw with boss M6×15
25
Crystal label of connecting plate between left and
right caps
- 385 -

Benelli TNT125 Specifications

General

Displacement	125 cc
Transmission	5-speed
Fuel System	EFI
Fuel Capacity	7.2 liters
Seat Height	780 mm
Dry Weight	116 kg
Bore x Stroke	54 mm x 54.5 mm
Starting System	Electric
Wheelbase	1215 mm
Engine Type	Single cylinder, 4-stroke, air-cooled
Front Suspension	Upside-down fork
Front Brake	Single disc
Rear Brake	Single disc
Front Tire	120/70-12
Rear Tire	130/70-12
Max Power	8.2 kW (11.1 Cv) @ 9500 rpm
Rear Suspension	Swing arm with lateral shock absorber with adjustable spring preload
