Benelli TNT125 Service Manual

severely, there may be large c
urrent and the large
current may fuse the fuse after the engine starts.
Warning
When replacing the fuse, make sure that the
current of new fuse matches the rated current of
specified fuse of that circuit. If the fuse with the
current which is higher than the rated current is
installed, the circuit or part may be damaged.
- 464 -

Benelli TNT125 Specifications

General

Displacement	125 cc
Transmission	5-speed
Fuel System	EFI
Fuel Capacity	7.2 liters
Seat Height	780 mm
Dry Weight	116 kg
Bore x Stroke	54 mm x 54.5 mm
Starting System	Electric
Wheelbase	1215 mm
Engine Type	Single cylinder, 4-stroke, air-cooled
Front Suspension	Upside-down fork
Front Brake	Single disc
Rear Brake	Single disc
Front Tire	120/70-12
Rear Tire	130/70-12
Max Power	8.2 kW (11.1 Cv) @ 9500 rpm
Rear Suspension	Swing arm with lateral shock absorber with adjustable spring preload
