P a g e | 144
UCM6510 IP PBX User Manual
Version 1.0.20.31
ACL Policy
Access Control List manages the IP addresses that can register to this
extension.
 Allow All: Any IP address can register to this extension.
 Local Network Address: Only IP addresses in the configured
network segments can register to this extension.
Local Network Address
Specifies allowed IP address or networks from where the extension can
be registered. Up to 10 entries are allowed.
Format: "xxx.xxx.xxx.xxx", "xxx.xxx.xxx.xxx/32", "[::]" or "[::]/128".
Codec Preference
Select audio and video codec for the extension. The available codecs are:
PCMU, PCMA, GSM, AAL2-G.726-32, G,726, G.722, G.729, G.723,
OPUS, iLBC, ADPCM, H.264, H.265, H.263, H.263p and RTX.
Table 33: SIP Extension Configuration Parameters – Features
Call Transfer
Presence Status
Select which presence status to set for the extension and configure call
forward conditions for each status. Six possible options are possible:
“Available”, “Away”, “Chat”, “Custom”, “DND” and “Unavailable”.
More details at [PRESENCE]
Call Forward Unconditional
Enable and configure the Call Forward Unconditional target number.
Available options for target number are:
 “None”: Call forward deactivated.
 “Extension”: Select an extension from dropdown list as CFU target.
 “Custom Number”: Enter a customer number as target. For
example: *97.
 “Voicemail”: Select an extension from dropdown list. Incoming calls
will be forwarded to voicemail of selected extension.
 “Ring Group”: Select a ring group from dropdown list as CFU target.
 “Queues”: Select a queue from dropdown list as CFU target.
 “Voicemail Group”: Select a voicemail group from dropdown list as
CFU target.
The default setting is “None”.
CFU Time Condition
Select time condition for Call Forward Unconditional. CFU takes effect only
during the selected time condition. The available time conditions are
“Office Time”, “Out of Office Time”, “Holiday”, “Out of Holiday”, “Out of
Office Time or Holiday” and “Specific”.
Notes:
 “Specific” has higher priority to “Office Times” if there is a conflict in
terms of time period.
 Specific Time can be configured in the Specific Time tab.
