UCM6510 IP PBX User Manual
Version 1.0.20.31
Figure 26: Create New Firewall Rule
Table 13: Firewall Rule Settings
Rule Name
Enter a name for the firewall rule.
Action
Select the action for the Firewall to perform.
 ACCEPT
 REJECT
 DROP
Type
Select the traffic type.
 IN
If selected, the Interface field will appear. Users must specify the interface
that the inbound rule will be applied to.
 OUT
Service
Select the connection type the rule will apply to.
 FTP
 SSH
 Telnet
 TFTP
 HTTP
 LDAP
 Custom
If selected, users must configure the Source IP and Port,Destination IP
Address and Port, and the Protocol fields that appear. If the source and
destination are left blank, the "Anywhere" values will be used.
The new rule will be listed at the bottom of the page with sequence number, rule name, action, protocol,
type, source, destination and operation. Users can click on to edit the rule or click on to delete the
rule. The UCM must be rebooted for the new rules to take effect.
