P a g e | 200
UCM6510 IP PBX User Manual
Version 1.0.20.31
Enable automatic recording for the calls using this trunk (for SIP trunk only).
The default setting is disabled. The recording files are saved in external
storage device if plugged in and can be accessed under Web
GUICDRRecording Files.
Select DAHDI line type. Default: Ascending
Allows external numbers the option to get directed to the extension that last
called them.
Notes:
Allows external numbers the option to get directed to the extension that
last called them.
Direct Callback option will be hidden if E&M Immediate or E&M Wink
is selected for the Edit T1 PortSignaling field due to not being
applicable.
Enable to detect Fax signal from the trunk during the call and send the
received Fax to the default Email address in Fax setting page under Web
GUICall FeaturesFax/T.38.
Note: If enabled, Fax Pass-through cannot be used.
Direct Outward Dialing (DOD) via Digital Trunks
Please refer to section [Direct Outward Dialing (DOD) via VoIP Trunks].
Digital Trunk Troubleshooting
After configuring the digital trunk on the UCM6510 as described above, and it does not work as expected,
users can start and download a signaling capture from the MaintenanceSignaling Troubleshooting
page for analysis.
Depending on the signaling selected for the digital trunk, users can go to following pages to capture trace:
PRI Signaling Trace: Web GUIMaintenanceSignaling TroubleshootingPRI Signaling Trace
SS7 Signaling Trace: Web GUIMaintenanceSignaling TroubleshootingSS7 Signaling Trace
MFC/R2 Signaling Trace: Web GUIMaintenanceSignaling TroubleshootingMFC/R2 Signaling
Trace
E&M Trace: Web GUIMaintenanceSignaling TroubleshootingE&M Immediate Record Trace
Here is the step to capture trace:
1. Click on "Start" to start capturing trace. The output result shows "Capturing..."
2. Once the test is done, click on "Stop" to stop the trace.
3. Click on "Download" to download the trace.
