UCM6510 IP PBX User Manual
Version 1.0.20.31
Figure 286: Trunk Status
Table 141: Trunk Status
Status
Display trunk status.
 Analog trunk/Digital trunk status:
Available
Busy
Unavailable
Unknown Error
Error Configured: Incorrect signaling configuration between the two
devices. For example, both of the devices are configured as CPE or NET.
 SIP Peer trunk status:
Unreachable: The hostname cannot be reached.
Unmonitored: This requires "Keep-alive" to be enabled for the trunk, not the
QUALIFY feature.
Reachable: The hostname can be reached.
 SIP Register trunk status:
Registered
Unrecognized Trunk
Trunks
Display trunk name
Type
Display trunk Type:
 Analog
 E1/T1/J1
 SIP
 IAX
Username
Display username for this trunk.
Port/Hostname/IP
Display Port for analog trunk, or Hostname/IP for VoIP (SIP/IAX) trunk.
