P a g e | 199
UCM6510 IP PBX User Manual
Version 1.0.20.31
Select alaw or ulaw. The default codec is ulaw for T1.
Select “esf” or “d4”. Default setting is esf.
Select B8ZS or AMI. The default setting is B8ZS for T1.
The option is only valid for E&M Wink signaling. The dial delay interval after
received WINK event in an outgoing call. The default value is 200ms.
Configure receive wink timing. The default setting is 300ms.
Digital Trunk Configuration
After configuring digital hardware, go to Web GUIExtension/TrunkDigital Trunks.
Click on "Create New Digital Trunk" to add a new digital trunk.
Click on to configure detailed parameters for the digital trunk.
Click on to configure Direct Outward Dialing (DOD) for the digital Trunk.
Click on to delete the digital trunk.
The digital trunk parameters are listed in the table below.
Table 57: Digital Trunk Configuration Parameters
Configure trunk name to identify the digital trunk.
Configure the digital channel group used by the trunk.
Configure to hide outgoing caller ID. The default setting is "No".
If enabled, the trunk CID will not be overridden by extension's CID when the
extension has CID configured. The default setting is "No".
Configure the Caller ID. This is the number that the trunk will try to use when
making outbound calls. For some providers, it might not be possible to set
the CallerID with this option and this option will be ignored.
Important Note: When making outgoing calls, the following priority order
rule will be used to determine which CallerID will be set before sending out
the call:
From user (Register Trunk Only) CID from inbound call (Keep Original
CID Enabled) Trunk Username/CallerID (Keep Trunk CID Enabled)
DOD Extension CallerID Number Trunk Username/CallerID (Keep
Trunk CID Disabled) Global Outbound CID.
Configure the new name of the caller when the extension has no CallerID
