P a g e | 219
UCM6510 IP PBX User Manual
Version 1.0.20.31
SLA STATION
UCM6510 supports SLA (Shared Line Appearance) that allows mapping the key with LED on a multi-line
phone to different external lines. When there is an incoming call and the phone starts to ring, the LED on
the key will flash in red and the call can be picked up by pressing this key. This allows users to know if the
line is occupied or not. The SLA function on the UCM6510 is similar to BLF but SLA is used to monitor
external line i.e., analog trunk on the UCM6510. Users could configure the phone with BLF mode on the
MPK to monitor the analog trunk status or press the line key pick up call from the analog trunk on the
UCM6510.
Create/Edit SLA Station
SLA Station can be configured on Web GUIExtension/TrunkSLA Station.
Figure 114: SLA Station
Click on “Create New SLA Station” to add an SLA Station.
Click on to edit the SLA Station. The following table shows the SLA Station parameters.
Click on to delete the SLA Station.
Table 65: SLA Station Configuration Parameters
Configure a name to identify the SLA Station.
Specify a SIP extension as a station that will be using SLA.
Existing Analog Trunks with SLA Mode enabled will be listed here.
Select a trunk for this SLA from the Available SLA Trunks list. Click on
to arrange the order. If there are multiple trunks selected,
when there are calls on those trunks at the same time, pressing the LINE
key on the phone will pick up the call on the first trunk here.
Configure the time (in seconds) to ring the station before the call is
considered unanswered. No timeout is set by default. If set to 0, there will
be no timeout.
