P a g e | 220
UCM6510 IP PBX User Manual
Version 1.0.20.31
Configure the time (in seconds) for delay before ringing the station when a
call first coming in on the shared line. No delay is set by default. If set to 0,
there will be no delay.
This option defines the competence of the hold action for one particular
trunk. If set to “open”, any station could hold a call on that trunk or resume
one held session; if set to “private”, only the station that places the trunk
call on hold could resume the session. The default setting is “open”.
Sample Configuration
1. On the UCM6510, go to Web GUI Extension/Trunk Analog Trunks page. Create analog trunk
or edit the existing analog trunk. Make sure “SLA Mode” is enabled for the analog trunk. Once enabled,
this analog trunk will be only available for the SLA stations created under Web GUI Extension/Trunk
SLA Station page.
Figure 115: Enable SLA Mode for Analog Trunk
Click on “Save”. The analog trunk will be listed with trunk mode “SLA”.
Figure 116: Analog Trunk with SLA Mode Enabled
2. On the UCM6510, go to Web GUIExtension/TrunkSLA Station page, click on “Create New SLA
Station”. Please refer to section [Create/Edit SLA Station] for the configuration parameters. Users can
create one or more SLA stations to monitor the analog trunk. The following figure shows two stations,
1002 and 1005, are configured to be associated with SLA trunk “fxo1”.
