P a g e | 54
UCM6510 IP PBX User Manual
Version 1.0.20.31
Hardware Testing
Select Test SVIP to verify hardware connections within the device. The result
will display on the LCD when the test is complete.
Protocol: Web access protocol (HTTP/ HTTPS). HTTPS is used by default.
Port: Web access port number, which is 8089 by default.
Enable SSH
Disable SSH
SSH access is disabled by default
Use The LED Indicators
The UCM6510 has LED indicators in the front to display connection status. The following table shows the
status definitions.
Table 4: UCM6510 LED Indicators
Power 1/Power 2
PoE
LAN
WAN
USB
SD
Phone 1 /Phone 2 (FXS)
Line 1/Line 2 FXO
Fast Blinking: Data Transferring
Slow Blinking: Trying to connect
Solid: Connected and working
Fast Blinking (0.5s on/0.5s off): No
connection is detected.
Slow Blinking (1s on/1s off): Connected but
the link is only working one-way
