P a g e | 213
UCM6510 IP PBX User Manual
Version 1.0.20.31
"Register IAX Trunk" type is selected.
Enter the password to register to the trunk from the provider when
"Register IAX Trunk" type is selected.
If selected, the trunk will be disabled.
Table 63: IAX Register Trunk Configuration Parameters
Configure a unique label to identify this trunk when listed in outbound rules,
inbound rules and etc.
Configure the IP address or URL for the VoIP provider’s server of the trunk.
If enabled, the trunk CID will not be overridden by extension's CID when
the extension has CID configured. The default setting is "No".
If selected, the trunk will be disabled.
Configure the Caller ID. This is the number that the trunk will try to use
when making outbound calls. For some providers, it might not be possible
to set the CallerID with this option and this option will be ignored.
Important Note: When making outgoing calls, the following priority order
rule will be used to determine which CallerID will be set before sending out
the call :
From user (Register Trunk Only) CID from inbound call (Keep Original
CID Enabled) Trunk Username/CallerID (Keep Trunk CID Enabled)
DOD Extension CallerID Number Trunk Username/CallerID (Keep
Trunk CID Disabled) Global Outbound CID.
Configure the name of the caller to be displayed when the extension has
no CallerID Name configured.
Enter the username to register to the trunk from the provider.
Enter the password to register to the trunk from the provider.
Select audio and video codec for the VoIP trunk. The available codecs are:
PCMU, PCMA, GSM, AAL2-G.726-32, G.726, G.722, G.729, G.723, ILBC,
ADPCM, H.264, H.265, H.263, H.263p.
Enable Heartbeat Detection
If enabled, the UCM6510 will regularly send SIP OPTIONS to the device
to check if the device is still online. The default setting is "No".
When "Enable Heartbeat Detection" option is set to "Yes", configure the
interval (in seconds) of the SIP OPTIONS message sent to the device to
