P a g e | 153
UCM6510 IP PBX User Manual
Version 1.0.20.31
Configure personal password when making outbound calls via trunk.
If enabled, the extension will be added to LDAP Phonebook PBX lists.
Configure the Music On Hold playlist to suggest to the bridged channel
when putting them on hold.
The maximum duration of call-blocking.
Table 38: IAX Extension Configuration Parameters – Specific Time
Click to add Time Condition to configure specific time for this extension.
Create New FXS Extension
The UCM6510 supports Foreign eXchange Subscriber (FXS) interface. FXS is used when user needs to
connect analog phone lines or FAX machines to the UCM6510.
To manually create new FXS user, go to Web GUIExtension/TrunkExtensions. Click on "Add" and a
new dialog window will show for users which need to make sure first to select the extension type to be FXS
Extension before proceeding to fill in the extension information. The configuration parameters are as
follows.
Table 39: FXS Extension Configuration Parameters – Basic Settings
The extension number associated with the user.
Select the FXS port to be assigned for this extension.
Configure the CallerID Number that would be applied for outbound calls
from this user.
Note: The ability to manipulate your outbound Caller ID may be limited by
your VoIP provider.
Assign permission level to the user. The available permissions are
“Internal”, “Local”, “National” and “International” from the lowest level to
the highest level. The default setting is “Internal”.
Note:
Users need to have the same level as or higher level than an outbound
rule’s privilege in order to make outbound calls using this rule.
Configure Voicemail. There are three valid options and the default option
is "Enable Local Voicemail".
Disable Voicemail: Disable Voicemail.
Enable Local Voicemail: Enable voicemail for the user.
Configure the password to access the extension's voicemail. A randomly
generated password is used by default and is highly recommended for
