P a g e | 242
UCM6510 IP PBX User Manual
Version 1.0.20.31
Pattern: Always prefixed with _
CallerID Pattern: Always prefixed with _
Prepend Trunk Name: Yes/No.
Prepend User Defined Name Enable: Yes/No.
Prepend User Defined Name: A string.
Alert-info: None, Ring 1, Ring 2… User should enter an Alert-info string following the values we
have in the Inbound route Alert-Info list.
Allowed to seamless transfer: [Extension_number]
Fax Detection: No, Yes.
Fax Type: Extension, Fax to Email.
Fax Destination: [Extension_number] or [Email address]
Inbound Multiple Mode: Yes/No.
Default Destination: By DID, Extension, Voicemail… User should enter a Default Destination string
following the values we have in the Inbound route Default Destination list.
Destination: An Extension number, Ring Group Extension…
Default Time Condition.
Mode 1: By DID, Extension, Voicemail… User should enter a Default Destination string following
the values we have in the mode 1 Default Destination list.
Mode 1 Destination: An Extension number, Ring Group Extension…
Mode 1 Time Condition.
Fax with Two Media
Since UCM's system is now based on Asterisk 13, fax re-invites that negotiate with multiple codecs are now
supported. If a re-invite contains both T.38 and PCMU/PCMA codecs, T.38 will be prioritized.
Blacklist Configurations
In the UCM6510, Blacklist is supported for all inbound routes. Users could enable the Blacklist feature and
manage the Blacklist by clicking on "Blacklist".
Select the checkbox for "Blacklist Enable" to turn on Blacklist feature for all inbound routes. Blacklist is
disabled by default.
Enter a number in "Add Blacklist Number" field and then click to add to the list. Anonymous can
also be added as a Blacklist Number.
To remove a number from the Blacklist, select the number in "Blacklist list" and click on or click
on button to remove all the numbers on the blacklist.
User can also export the inbound route blacklist by pressing on button.
