Figure 120: Blacklist Import/Export
Scheduled Sync
Outbound Routes can be synced from a UTF-8 encoded CSV file located in the configured TFTP server.
CSV files can be opened using programs such as Notepad and saved as a UTF-8 encoded file.
Table 68: Sync Outbound Routes
Sync Outbound Routes
Scheduled Sync
Enable Scheduled Sync option.
Server Address
Enter the TFTP server address (e.g., 192.168.1.2:69).
File Name
Enter the file name.
Sync Time
Enter the sync time (24hr format). Valid range is 0-23.
Sync Frequency
Create new sync every x day(s). The valid range is 1 to 30.
PIN Groups
The UCM6510 supports pin group. Once this feature is configured, users can apply pin group to specific
outbound routes. When placing a call on pin protected outbound routes, caller will be asked to input the
group pin number, this feature can be found on the webGUIExtension/TrunkOutbound
RoutesPIN Groups.
Table 69: Outbound Routes/PIN Group
Name
Configure the name of the group
Record In CDR
Configure whether or not to display the used PIN group and name in a call's CDR
entry.
PIN Number
Configure the PIN that will be required to dial out.
