P a g e | 375
UCM6510 IP PBX User Manual
Version 1.0.20.31
Configure to enable or disable strict RTP protection. If enabled, RTP
packets that do not come from the source of the RTP stream will be
dropped. The default setting is "Disable".
Configure to enable or disable RTP Checksums on RTP traffic. The default
setting is "Disable".
Configure whether to support ICE, ICE is the integrated use of STUN and
TURN structure to provide reliable VoIP or video calls and media
transmission, via a SIP request/ response model or multiple candidate
endpoints exchanging IP addresses and ports, such as private addresses
and TURN server address. It is enabled by default.
Configure TURN server address. TURN is an enhanced version of the
STUN protocol and is dedicated to the processing of symmetric NAT
problems.
Configure turn server account name.
Configure turn server account password.
Configure STUN server address, STUN protocol is a Client / Server – is
also a Request / Response protocol, where it is used to check the
connectivity between the two terminals, such as maintaining NAT binding
entries keep alive agreement.
The default STUN Server is stun.ipvideotalk.com
Valid format:
[(hostname | IP-address) [':' port]
The default port number is 3478 if not specified.
Payload
The UCM6510 payload type for audio codecs and video codes can be configured here.
Table 112: Internal Options/Payload
Configure payload type for ADPCM (G.726, 32kbps, AAL2 codeword
packing). The default setting is 112.
Configured payload type for DTMF. The default setting is 101.
Configure to enable/disable G.721 compatible. The default setting is Yes.
Configure the payload type for G.726 if "G.721 Compatible" is disabled.
The default setting is 111.
Configure the payload type for iLBC. The default setting is 97.
Configure the payload type for H.264. The default setting is 99.
