UCM6510 IP PBX User Manual
Version 1.0.20.31
Note: If a current SIP trunk is disabled, UCM6510 will send UNREGISTER
message (REGISTER message with expires=0) to the SIP provider.
TEL URI
If the trunk has an assigned PSTN telephone number, this field should be
set to "User=Phone". Then a "User=Phone" parameter will be attached to
the Request-Line and TO header in the SIP request to indicate the E.164
number. If set to "Enable", "Tel:" will be used instead of "SIP:" in the SIP
request. The default setting is disabled.
Caller ID
Configure the Caller ID. This is the number that the trunk will try to use
when making outbound calls. For some providers, it might not be possible
to set the CallerID with this option and this option will be ignored.
Important Note: When making outgoing calls, the following priority order
rule will be used to determine which CallerID will be set before sending out
the call :
 From user (Register Trunk Only)  CID from inbound call (Keep
Original CID Enabled)  Trunk Username/CallerID (Keep Trunk CID
Enabled)  DOD  Extension CallerID Number  Trunk
Username/CallerID (Keep Trunk CID Disabled)  Global Outbound
CID.
Need Registration
Select whether the trunk needs to register on the external server or not
when "Register SIP Trunk" type is selected. The default setting is No.
Username
Enter the username to register to the trunk from the provider when
"Register SIP Trunk" type is selected.
Password
Enter the password to register to the trunk from the provider when
"Register SIP Trunk" is selected.
Auth ID
Enter the Authentication ID for "Register SIP Trunk" type.
Auto Record
Enable automatic recording for the calls using this trunk (for SIP trunk
only). The default setting is disabled. The recording files can be accessed
under Web GUICDRRecording Files.
Direct Callback
Allows external numbers the option to get directed to the extension that
last called them. For Example: User 2002 has dialed external number
061234575 but they were not reachable, once they have received missed
call notification on their phone, they would mostly call back the number, if
the option “Direct Callback” is enabled then they will be directly bridged to
user 2002 regardless of the configured inbound destination.
Table 60: SIP Register Trunk Configuration Parameters
Basic Settings
Provider Name
Configure a unique label to identify this trunk when listed in outbound rules,
inbound rules and etc.
