UCM6510 IP PBX User Manual
Version 1.0.20.31
Figure 246: General call Failure Prompts
PBX Settings/Jitter Buffer
Table 110: Internal Options/Jitter Buffer
SIP Jitter Buffer
Enable Jitter Buffer
Select to enable jitter buffer on the sending side of the SIP channel. The
default setting is "No".
Jitter Buffer Size
Configure the time (in ms) to buffer. This is the jitter buffer size used in
"Fixed" jitter buffer or used as the initial time for "adaptive" jitter buffer. The
default setting is 100.
Max Jitter Buffer
Configure the maximum time (in ms) to buffer for "Adaptive" jitter buffer
implementation or used as the jitter buffer size for "Fixed" jitter buffer
implementation. The default setting is 200.
Implementation
Configure the jitter buffer implementation on the sending side of a SIP
channel. The default setting is "Fixed".
 Fixed
The size is always equal to the value of "Max Jitter Buffer".
 Adaptive
The size is adjusted automatically and the maximum value equals to
the value of "Max Jitter Buffer".
PBX Settings/RTP Settings
RTP Settings
Table 111: Internal Options/RTP Settings
RTP Start
Configure the RTP port starting number. The default setting is 10000.
RTP End
Configure the RTP port ending address. The default setting is 20000.
