UCM6510 IP PBX User Manual
Version 1.0.20.31
Extensions
Extensions Status can be seen from the same configuration page, users can go under Web
GUIExtension/TrunkExtensions and following page will be displayed listing the extensions and their
status information.
Figure 287: Extension Status
Table 142: Extension Status
Status
Display extension number (including feature code). The color indicator has the
following definitions.
 Green: Free
 Blue: Ringing
 Yellow: In Use
 Grey: Unavailable
Presence Status
Display the presence status of the extension.
Extension
Display the extension number.
Name
First name and last name of the extension.
IP and Port
Display the IP and port number of the registered device.
Email
Display Email Notification status for the extension.
SIP Account email notification has not been sent.
SIP Account email notification has been sent.
Type
Displays extension type.
 SIP User
 IAX User
 Analog User
