P a g e | 69
UCM6510 IP PBX User Manual
Version 1.0.20.31
password are required for authentication, which should be provided by the network administrator obtained
from the RADIUS server. If “EAP-TLS” or “EAP-PEAPv0/MSCHAPv2” is used as the 802.1X mode, users
will also need upload 802.1X CA Certificate and 802.1X Client Certificate, which should be also generated
from the RADIUS server.
Table 7: UCM6510 Network Settings802.1X
Select 802.1X mode. The default setting is “Disable”. The supported 802.1X modes
are:
EAP-MD5
EAP-TLS
EAP-PEAPv0/MSCHAPv2
Enter 802.1X mode Identity information.
Enter 802.1X mode MD5 password information.
Select 802.1X certificate from local PC and then upload.
802.1X Client
Certificate
Select 802.1X client certificate from local PC and then upload.
Static Routes
A static route is a pre-determined path that the network traffic travels to reach a specific host or network.
On the UCM6510, the static route function allows the device to use manually configured routes, instead of
dynamically assigned routes or the default gateway. Static routes can be used to define a route when no
others are available or can serve as complementary routes alongside existing routes as failover routes with
existing routing on the UCM6510 as a failover backup, and etc.
Click on to create a new IPv4 static route or click on
to create a new IPv6 static route. The configuration parameters are listed in the table below.
Once added, users can select to edit the static route.
Select to delete the static route.
Static routes configuration can be reset from LCD menuNetwork Menu.
Table 8: UCM6510 Network SettingsStatic Routes
Configure the destination IPv4 address or the destination IPv6 subnet for the
UCM6510 to reach using the static route.
Example:
