P a g e | 293

UCM6510 IP PBX User Manual

Version 1.0.20.31

PAGING AND INTERCOM GROUP

Paging and Intercom Group can be used to make an announcement over the speaker on a group of phones.

Targeted phones will not ring but answer immediately using speaker. The UCM6510 paging and intercom

can be used via feature code to a single extension or a paging/intercom group. This section describes the

configuration of paging/intercom group under Web GUICall FeaturesPaging/Intercom.

Configure Paging/Intercom Group

 Click on "Add" to add paging/intercom group.

 Click on to edit the paging/intercom group.

 Click on to delete the paging/intercom group.

 Click on "Paging/Intercom Group Settings" to edit Alert-Info Header. This header will be included in the

SIP INVITE message sent to the callee in paging/intercom call.

Configure Multicast Paging

Figure 180: Multicast Paging
