Table 50: Analog Hardware Configuration Parameters
Select country to set the default tones for dial tone, busy tone, ring tone and
etc to be sent from the FXS port. The default setting is “United States of
America (USA)”.
Select country to set the On-Hook Speed, Ringer Impedance, Ringer
Threshold, Current Limiting, TIP/RING voltage adjustment, Minimum
Operational Loop Current, and AC Impedance as predefined for your
country’s analog line characteristics. The default setting is “USA”.
Select country to set the On-Hook Speed, Ringer Impedance, Ringer
Threshold, Current Limiting, TIP/RING voltage adjustment, Minimum
Operational Loop Current, and AC Impedance as predefined for your
country’s analog line characteristics. The default setting is “United States of
America (USA)”.
Configure to enable or disable override Two-Wire Impedance Synthesis
(TISS). The default setting is No.
If enabled, users can select the impedance value for Two-Wire Impedance
Synthesis (TISS) override. The default setting is 600Ω.
Select the codec to be used for analog lines. North American users should
choose PCMU. All other countries, unless already known, should be
assumed to be PCMA. The default setting is PCMU.
Note: This option requires system reboot to take effect.
Configure whether normal ringing voltage (40V) or maximum ringing
voltage (89V) for analog phones attached to the FXS port is required. The
default setting is “Normal”.
Configure to increase the ringing speed to 25HZ. This option can be used
with “Low Power” option. The default setting is “Normal”.
Configure the peak voltage up to 50V during “Fast Ringer” operation. This
option is used with “Fast Ringer”. The default setting is “Normal”.
If set to “Full Wave”, false ring detection will be prevented for lines where
Caller ID is sent before the first ring and proceeded by a polarity reversal,
as in UK. The default setting is “Standard”.
Configure the type of Message Waiting Indicator on FXS lines. The default
setting is “FSK”.
FSK: Frequency Shift Key Indicator
NEON: Light Neon Bulb Indicator.
Allows users to adjust the tolerance of the FXO ringing frequency. 63Hz is
considered the standard value and is selected by default.
