UCM6510 IP PBX User Manual
Version 1.0.20.31
Table 85: Multicast Paging Configuration Parameters
Name
Configure paging/intercom group name.
Type
Select “Multicast Paging”.
Extension
Configure the paging/intercom group extension.
Multicast IP Address
The allowed multicast IP address range is 224.0.1.0 - 238.255.255.255.
Note: This field appears only when “Type” is set to “Multicast Paging”.
Maximum Call Duration
Specify the maximum call duration in seconds. The default value 0 means no
limit.
Custom Prompt
Configure a custom prompt to play to paging callees. Users can now directly
upload custom prompts from this page. They do not need to be redirected
anymore.
Multicast IP Address
Configure the multicast IP address that endpoints will listen to.
Port
Configure the port for multicast paging.
Note: This field appears only when “Type” is set to “Multicast Paging”.
Configure 2-way Intercom
Figure 181 : 2-way Intercom
Table 86: 2-way Intercom Configuration Parameters
Name
Configure paging/intercom group name.
