Grandstream Networks UCM6510 User Manual

P a g e | 164
UCM6510 IP PBX User Manual
Version 1.0.20.31
Figure 84: Manage Extensions
 Status
Users can see the following icon for each extension to indicate the SIP status.
Green: Free
Blue: Ringing
Yellow: In Use
Grey: Unavailable
 Edit single extension
Click on to start editing the extension parameters.
 Reset single extension
Click on to reset the extension parameters to default (except concurrent registration).
Other settings will be restored to default in MaintenanceUser ManagementUser Information
except username and permissions and delete the user voicemail prompt and voice messages.
 Reboot the user
Click on to send NOTIFY reboot event to the device which has an UCM6510 extension already
registered. To successfully reboot the user, “Zero Config” needs to be enabled on the UCM6510 Web
GUIValue-added FeaturesZero ConfigAuto Provisioning Settings.
 Delete selected extensions
Click on the button to delete a single extension. Users can also select multiple extensions and
click on the Delete button to delete several extensions at once.
 Modify selected extensions
Select the checkbox for the extension(s). Then click on “Modify Selected Extensions” to edit the
extensions in a batch.
Export Extensions
UCM extensions can be exported to a CSV file. Different extension types (SIP, IAX, FXS) cannot be
exported to the same CSV file. To export extensions, click on the Export button and select the extension
type to export.
