P a g e | 191
UCM6510 IP PBX User Manual
Version 1.0.20.31
Configure whether to play the ringback tone from local UCM6510 or not. If
enabled, the local UCM6510 will play ringback tone to the caller. Otherwise,
the caller will listen to the tone from peer device. Default setting is disabled.
Select switch type.
EuroISDN: EuroISDN (common in Europe)
NI2: National ISDN type 2 (common in the US)
DMS100: Nortel DMS100
4ESS: AT&T 4ESS
5ESS: Lucent 5ESS
NI1: old national ISDN type 1
Q.SIG
Select whether to use CRC4 or not.
This setting is used to specify the type of the callee number. The service
provider will usually verify this. The default setting is “unknown”. In some
very unusual circumstances, you may need set to “Dynamic” or
“Redundant”.
Note:
When one type is selected, you might not be able to dial another playlist of
numbers. For example, if “National” is configured, you will not be able to
dial local or international numbers.
This setting is used to specify the type of the caller number. The service
provider will usually verify this.
Indicates the D channel for control.
International Prefix
National Prefix
Local Prefix
Private Prefix
Unknown Prefix
Configure the prefix in PRI Local Dial Plan and PRI Dial Plan for each type.
Configure PRI T310 Timer (in seconds). The default value is 10 seconds.
Select the PRI Indication.
outofband: Use RELEASE, DISCONNECT or other messages with
CAUSE to indicate call progress (e.g., cause: unassigned number or
user busy).
inband: use in-band tones to play busy or congestion signal to the other
side. This is the default setting.
The interval that restarts idle channels.
This setting is used to set up the ChannelID in SETUP message. If enabled,
To Next Page
