UCM6510 IP PBX User Manual
Version 1.0.20.31
Keep Trunk CID
If enabled, the trunk CID will not be overridden by extension’s CID when
the extension has CID configured. The default setting is “No”.
NAT
Turn on this option when the PBX is using public IP and communicating
with devices behind NAT. If there is one-way audio issue, usually it is
related to NAT configuration or SIP/RTP port configuration on the firewall.
Disable This Trunk
If selected, the trunk will be disabled.
Note: If a current SIP trunk is disabled, UCM6510 will send UNREGISTER
message (REGISTER message with expires=0) to the SIP provider.
TEL URI
If the trunk has an assigned PSTN telephone number, this field should be
set to "User=Phone". Then a "User=Phone" parameter will be attached to
the Request-Line and TO header in the SIP request to indicate the E.164
number. If set to "Enable", "Tel:" will be used instead of "SIP:" in the SIP
request. The default setting is disabled.
Caller ID
Configure the Caller ID. This is the number that the trunk will try to use
when making outbound calls. For some providers, it might not be possible
to set the CallerID with this option and this option will be ignored.
Important Note: When making outgoing calls, the following priority order
rule will be used to determine which CallerID will be set before sending out
the call: CID from inbound call (Keep Original CID Enabled)  Trunk
Username/CallerID (Keep Trunk CID Enabled)  DOD  Extension
CallerID Number  Trunk Username/CallerID (Keep Trunk CID Disabled)
 Global Outbound CID.
CallerID Name
Configure the name of the caller to be displayed when the extension has
no CallerID Name configured.
From Domain
Configure the domain name of the SIP user account. This will overwrite
the domain in the "From" header. Example: If the user account is
"1234567", setting "trunk.UCM6510.provider.com" as the From Domain
value will result in the following From header:
"sip:1234567@trunk.UCM6510.provider.com"..
Transport
Configure the SIP transport protocol to be used in this trunk.
 UDP
 TCP
 TLS
The default setting is "UDP".
Direct Callback
Allows external numbers the option to get directed to the extension that
last called them.
For Example: User 2002 has dialed external number 061234575 but they
were not reachable, once they have received missed call notification on
