UCM6510 IP PBX User Manual
Version 1.0.20.31
Manually enter the remote extensions in the peer/register trunk to be
monitored in the event list.
Valid format: 5000,5001,9000
Event List BLF can be used to monitor remote LDAP extensions on VoIP trunks. SIP endpoints will need to
support event list BBLF to monitor remote extensions.
When an event list is created on the UCM and remote extensions are added to the list, the UCM will send
out SIP SUBSCRIBE to the remote UCM to obtain the remote extension status. When the SIP end points
register and subscribe to the local UCM event list, it can obtain the remote extension status from this event
list.
Once successfully configured, the event list page will show the status of total extension and subscribers for
each event list. Users can also select the event URI to check the monitored extension's status and the
subscribers' details.
--------------------------------------------------------------------------------------------------------------------------------------------
Notes:
To configure LDAP sync, please go to UCM6510 Web GUIExtension/TrunkVoIP Trunk. You will
see "Sync LDAP Enable" option. Once enabled, please configure password information for the remote
peer UCM6510 to connect to the local UCM6510. Additional information such as port number, LDAP
outbound rule, LDAP Dialed Prefix will also be required. Both the local UCM6510 and remote UCM6510
need enable LDAP sync option with the same password for successful connection and synchronization.
Currently LDAP sync feature only works between two UCMs.
(Theoretically) Remote BLF monitoring will work when the remote PBX being monitored is non-
UCM6510 PBX. However, it might not work the other way around depending on whether the non-
UCM6510 PBX supports event list BLF or remote monitoring feature.
--------------------------------------------------------------------------------------------------------------------------------------------
