1024 HEIDENHAIN Technical Manual MANUALplus 620
MP_speedTolerance
Rotational speed (feed rate) window
Available from NCK software version: 597 110-01.
Format: Numerical value
Input: 0.000 000 01 to 100 [%]
Default: 10 [%]
Access: LEVEL3
Reaction: RUN
MP_timeSpeedOK
Hysteresis time for monitoring the speed deviation
Available from NCK software version: 597 110-01.
Format: Numerical value
Input: 0.006 to 10 [s]
Default: 0.01 [s]
Access: LEVEL3
Reaction: RUN
MP_minFeed
Applies only to spindles: minimum spindle speed
Available from NCK software version: 597 110-01.
Format: Numerical value
Input: 0.000 000 000 to 36 000 000 [mm/min] or [°/min]
Default: 0
Access: LEVEL3
Reaction: RUN
The NC provides the information "rotational speed reached" in
NN_SpiSpeedOK.
PLC operand / Description Ty p e
NN_SpiSpeedOK
Spindle speed reached
0: Spindle speed not reached
1: Spindle speed reached
M
