HEIDENHAIN MANUALPLUS 620 Technical Manual

January 2012 3.20 Encoder Connections 243
3.20.2 Position encoder input
X201 to X206:
Position encoder
1V
PP
Pin layout:
CC 6106 Adapter cable 309 783-xx
Adapter cable 310 199-xx
Encoder
Male Assignment Female Color Female Male Color
1+5 V (U
P
) 1 Brown/Green 12 12 Brown/Green
20 V (U
N
) 2 White/Green 10 10 White/Green
3A+ 3 Brown 5 5Brown
4 A– 4 Green 6 6 Green
5 Do not assign 5
6 B+ 6 Gray 8 8 Gray
7 B– 7 Pink 1 1 Pink
8 Do not assign 8
9 +5 V (sensor) 9 Blue 2 2 Blue
10 R+ 10 Red 3 3 Red
11 0 V (sensor) 11 White 11 11 White
12 R– 12 Black 4 4 Black
13 0 V 13
14 Do not assign 14 Violet 7 7 Violet
15 Do not assign 15
Hsg. External shield Hsg. External shield Hsg. Hsg. External shield
Note
The interface complies with the requirements of EN 50178 for "low voltage
electrical separation."
