628 HEIDENHAIN Technical Manual MANUALplus 620
6.3.2 Programmable axes
In the parameter object CfgProgAxis, define and describe all axes that are
programmable and/or are displayed. This description is independent of the
assignment to NC channels.
For information about programmable axes, see "Standard coordinates" on page
627.
The name entered in MP_axName is used for programming/editing and in the
position display.
MP_axName
Designation of the axis for position display
Available from NCK software version: 597 110-01.
Format: String
Input: Max. 1 letter
e.g.: X, Y, Z, A, B, C, U, V, W
Default: –
Access: LEVEL3
Reaction: RESET
MP_dir
Spatial orientation of the axis or center of rotation
Available from NCK software version: 597 110-01.
Format: Selection menu
Selection: XAxis
Motion/rotation in X direction
YAxis
Motion/rotation in Y direction
ZAxis
Motion/rotation in Z direction
SpecAxis
Free/undefined spatial orientation, e.g. for spindle
Default: –
Access: LEVEL3
Reaction: RESET
Settings in the configuration editor MP number
Axes
CfgProgAxis
[Key name of the axis]
axName
dir
progKind
index
relatedAxis
300001
300002
300003
300004
300005
