HEIDENHAIN MANUALPLUS 620 Technical Manual

January 2012 6.15 Reference Marks 797
6.15.4 Defining the process of traversing the reference marks
The parameter object CfgReferencing is not required for:
 Virtual axes (MP_axisMode = Virtual)
You define the process of traversing the reference marks in the following
machine parameters:
 In MP_refDirection and MP_refFeedHigh (for rotary encoders also in
MP_refFeedLow) you define the direction and velocity for traversing the
reference marks.
 In MP_refAxis, define the sequence of axes for traversing the reference
marks.
 In MP_refType you select the functional sequence (type of reference
marks) for each axis.
Settings in the configuration editor MP number
Axes
ParameterSets
[Key name of the parameter set]
CfgReferencing
refType
refSwitchActive
refFeedLow
refFeedHigh
refDirection
400401
400404
400406
400407
400408
