7.12.11 Configuring the tool carrier
The following tool carriers are preconfigured in the basic configuration:
 Multifix quick change tool holder (factory default setting)
 Tool turret
 Multifix and tool turret
Depending on the three configurations named above, the following key names
are assigned to the tool carriers in the control:
Enter the settings described below in the configuration editor.
Multifix as tool
carrier
The tool carrier TH1_MULTI and the tool holder TH1_TM001_MULTI are
already configured in the standard configuration.
 In the two entities listed below, enter the key name TH1_MULTI for the
multifix tool carrier.
Machine
configuration
Multifix Tool turret Multifix and tool
turret
Multifix TH1_MULTI - TH2_MULTI
Tool turret - TH1_REV TH1_REV
Settings in the configuration editor MP number
Channels
ChannelSettings
CH_NC1
CfgAssignAggregate
assignToolHolder
[0]: TH1_MULTI
Aggregates
General
CfgAggregateKeys
toolHolderKeys
[0]: TH1_MULTI
203901
600001
