1196 HEIDENHAIN Technical Manual MANUALplus 620
6.22.7 Hardware group
Hardware
information of the
CC (CC HW Info)
To select the CC HW Info function:
 Press the Login Ipo (or Login SimIpo) soft key.
 Press the HW soft key.
 Press the CC HW Info soft key.
On the left side of the screen the OLM shows the variables as they are
provided by the CC (first CC in the left column, and second CC in the right
column):
Note
The hardware information displayed for the CC is only valid if a CC with a
parallel interface is used (no HSCI).
Variable Display
CC-Type
ActiveAxes Displays the available axes in bit-encoded
representation.
CtrlType Provides information on hardware and software
versions, etc.
TestVersion Information on the DSP software. Indicates either the
letter of a test version or the number of a DSP software
service pack. The MC must take this additional
information into account.
LinkDate Contains the software generation in 32 bits (Unix
format)
SoftIdent Contains the software ID and the version code.
ReadyInc After processing the remaining identification cells, the
variable is incremented by the controller program or
boot program to allow an "activity check."
