HEIDENHAIN MANUALPLUS 620 Technical Manual

384 HEIDENHAIN Technical Manual MANUALplus 620
4.7.2 Activating the machine-parameter subfile
MP subfiles can be activated in the configuration editor or by the PLC.
Activation in the
configuration editor
Use the LOAD MP SUBFILE soft key to activate individual subfiles.
Soft key Function
Calls the function for activating/editing MP subfiles.
The selected MP subfile is loaded and activated. The
parameters are effective immediately and can be edited in the
configuration editor.
The selected MP subfile is opened only for editing and is not
effective. For example, this function can also be used to edit
reset parameters in MP subfiles without having to restart the
MANUALplus 620.
