746 HEIDENHAIN Technical Manual MANUALplus 620
6.11.5 Axis mirroring on lathes (as of NC software 548328-03)
Axis mirroring on lathes is required, for example, when carrying out machining
operations above or below the turning center or on the rear side. Such axis
mirroring is done within a kinematics group; there is no kinematics change.
Axis mirroring is activated/deactivated either via NC commands or by
assigning the activation/deactivation to a tool holder.
With the tool holder (parameter object CfgToolMount), you can control axis
mirroring with the following parameters:
MP_kinModelToModify: Subkinematics to be replaced of the axis or axes
to be mirrored
MP_kinModel: Subkinematics of the mirrored axis/axes, which is to be
activated
Axis mirroring that is configured with the tool holder will be activated when the
tool holder is inserted. Axis mirroring will remain active until the next tool
change.
MP_kinModelToModify
Keys of the subkinematics to be replaced
Available from NCK software version: 597 110-04.
Format: Array [0...99]
Default: -
Access: LEVEL3
Reaction: RESET
MP_kinModel
Keys of the subkinematics to be activated
Available from NCK software version: 597 110-04.
Format: Array [0...99]
Default: -
Access: LEVEL3
Reaction: RESET
Settings in the configuration editor MP number
Aggregates
ToolMount
[Key name of the tool holder]
CfgToolMount
kinModelToModify
kinModel
600418
600419
