January 2012 3.25 Data Interfaces 265
3.25 Data Interfaces
X26, X116: Ethernet
interface RJ45-port
Maximum cable length:
Unshielded: 100 m
Shielded: 400 m
Network topology: Star configuration
This means a hub serves as a central node that establishes the connection to
the other participants.
Maximum data transfer rate:
For integration into the company network via NFS or SMB protocol:
10 or 100 Mbps
For LSV2 protocol (in conjunction with TNCremoNT or RemoTools):
2 to 5 Mbps (depending on file type and network utilization)
Face of the connector:
Danger
The Ethernet interfaces of the MC 6xxx comply with the requirements of
PELV ("low voltage electrical separation") according to EN 61800-5-1 and are
powered internally by 24 V NC. All devices connected to these Ethernet
interfaces must comply with the requirements of SELV or PELV according
to EN 61800-5-1.
RJ45 connection (female) 8-pin Assignment
1TX+
2TX
3REC+
4 Do not assign
5 Do not assign
6REC
7 Do not assign
8 Do not assign
Housing External shield
1
8
