HEIDENHAIN MANUALPLUS 620 Technical Manual

January 2012 8.6 M Functions (M Strobe) 1549
8.6.2 Configuration of M functions
Transfer of the M
function
If there is more than one M function number with the same transfer
parameters, the M function numbers can be defined in a parameter object.
 Multiple M codes in the parameter object:
• MP_min: Code of the first M function
• MP_max: Greatest M code of the group
 One M code in the parameter object:
• MP_min: M code of the parameter object
• MP_max: No entry
If MP_code is defined, the NC transfers the programmed M code in the PLC
word marker defined in MP_code and other data of the M function in the PLC
word marker defined in MP_data.
Settings in the configuration editor MP number
System
PLC
CfgPlcMStrobe
[Key name of M strobe]
min
max
signal
acknowledge
code
data
revoke
split
track
singular
blockEnd
blockSearch
sync
macro
103901
103902
103903
103904
103905
103906
103907
103908
103914
103910
103911
103912
103913
103914
