HEIDENHAIN MANUALPLUS 620 Technical Manual

January 2012 3.4 HSCI 171
3.4.3 HSCI interface
Face of the connector:
X500
X501
X502
Pin layout:
The order of the HSCI participants at X500 of the MC is freely selectable. Each
HSCI participant is assigned its HSCI address based on its position in the HSCI
chain, see page 170.
Pin layout of the HSCI cable:
1
8
ID 618893-xx
Female Color Assignment Female
1 White/Green Data 1
2 Green Data 2
3 White/Orange Data 3
4 Not assigned Not assigned 4
5 Not assigned Not assigned 5
6OrangeData6
7 Not assigned Not assigned 7
8 Not assigned Not assigned 8
