1432 HEIDENHAIN Technical Manual MANUALplus 620
Configuration as
external spindle
In order to operate an externally driven tool (e.g.drilling machine via spindle S2)
only by the PLC without an additional control loop, you can configure the
driven tool as an external spindle.
To configure a spindle as an external spindle, enter the value None in
MP_axisHw. You must also enter the value PlcControlled in MP_axisMode.
7.12.4 Driven tool
A driven tool powered by spindle S2 is preconfigured in the standard
configuration of the MANUALplus 620.
Configuration
without driven tool
Remove spindle S2 from the configuration if your machine is operated without
a driven tool.
 Remove spindle S2 from the axisList and spindleIndices lists of the
CfgAxes entity.
 Remove kinematics that contain spindle S2 (K1_CH1_S12_C1 and
K2_CH1_S12)
Settings in the configuration editor MP number
Axes
PhysicalAxis
[Key name of the axis]
CfgAxis
axisHw
axisMode
300104
300105
Note
For external spindles, you can only enter feed rate per minute (G94) and
constant speed (G97) when entering the feed rate and rotational speed in
the TSF menu.
Settings in the configuration editor MP number
System
CfgAxes
axisList
[0]: X1
[1]: Z1
[2]: S1
[3]: S2
spindleIndices
[0]: S1
[1]: S2
100001
100002
