January 2012 7.12 Configuration of the Lathe 1433
When using the new kinematic model (as of NC SW 548 328-03):
When using the old kinematic model (up to NC SW 548 328-02):
Configuration with
driven tool
If you want to reinsert spindle S2, then you must undo the steps described in
the section above.
Settings in the configuration editor MP number
Channels
ChannelSettings
[Key name of the machining channel]
CfgKinList
kinCompositeModels
[0]: K1_CH1_S12_C1
[1]: K2_CH1_S12
[2]: K3_CH1_S1_C1
[3]: K4_CH1_S1
203001
Settings in the configuration editor MP number
Channels
ChannelSettings
[Key name of the machining channel]
CfgChannelAxes
kinModels
[0]: K1_CH1_S12_C1
[1]: K2_CH1_S12
[2]: K3_CH1_S1_C1
[3]: K4_CH1_S1
200306
When reinserting spindle S2 into your configuration, do not reverse the
order of the steps described in the section above!
