January 2012 6.18 Spindles 1037
6.18.10 Spindle of the kinematics model (until NC software 548 328-02)
In MP_activeSpindle you specify the spindle used in the kinematic model.
This assignment is required for different calculations (for example: calculate
feed per revolution, determine tool life, etc.)
MP_activeSpindle
Key of the active spindle of this kinematic model
Available from NCK software version: 597 110-01.
Format: String
Input: The key name of the spindle is read from CfgAxes/
spindleIndices, e.g. "S", "Spindle1", etc.
Default: –
Access: LEVEL3
Reaction: RUN
For more information on the configuration of the machine kinematics of your
control, see "Machine Kinematics (Up to NC Software 548 328-02)" on page
747
Settings in the configuration editor MP number
Channels
Kinematics
CfgKinModel
[Key name of the kinematic model]
activeSpindle 200011
