1696 HEIDENHAIN Technical Manual MANUALplus 620
8.15.31 EQUAL TO (==)
Syntax: == (EQUAL)
Operands: B, W, D, K
Action:
This command sets off a direct transition from word to logical processing.
Compare the content of the word accumulator with the content of the
addressed operand. If the word accumulator and the operand are equal, the
condition is true and the control sets the logic accumulator to 1. If they are not
equal, the logic accumulator is set to 0. The comparison takes place over the
number of bits corresponding to the operand:
where B = 8 bits, W = 16 bits, and D = K = 32 bits.
Example:
Compare a constant with the content of double word D8, and assign the result
to marker M500.
Initial state:
Constant = 16 000 (dec)
Double word D8 = 15 000 (dec)
Marker M300 = ?
Function STL Accumulator
content
Operand content
Load the constant into the
word accumulator.
L
K16000
16000
Compare the content of
the word accumulator
with the operand content
D8; if not equal, set the
logic accumulator to 0.
== D8 0 15000
Assign the result to
marker M500.
= M500 0 0
