1486 HEIDENHAIN Technical Manual MANUALplus 620
8.1.2 HEIDENHAIN PLC basic program
A PLC basic program for the control is available from HEIDENHAIN. This
comprehensive PLC program serves as a basis for adapting the control to the
requirements of the respective machine.
You need the PLCdesignNT software to adapt the PLC basic program.
Registered customers can download the current version of the PLC basic
program from the "HESIS-Web Including Filebase" on the Internet (http://
hesis.heidenhain.de).
The PLC basic program provides the following functions:
Controlling all axes
Positioning the axes after reference run
Clamped axes
Homing the axes, reference end positions
Compensating the axis temperature
Feed rate control
Controlling and orienting the spindle
Spindle brake
Gear switching via M functions
C axis via main drive
C axis with separate drive
Positioning of the tool turret with three-phase motor
Servo turret (one drive for the turret wheel and the driven tool)
Tool change for multifix tools
PLC soft keys
Displaying and managing PLC error messages
Positioning the PLC axis (example)
Hydraulic control
Hydraulic chuck
Sleeve 2, pressure
Coupled tailstock
Steady rest 2, pressure
Turret control via Sauter switch module
Electronic handwheels (with C or Y axis assignment)
Controlling the coolant system
Handling M functions
Lubrication
Chip conveyor
Touch probes
Controlling the doors
If you have any questions regarding the PLC basic program, please contact
the HEIDENHAIN PLC hotline.
Telephone: +49 / 8669 / 31-3102
E-mail: service.plc@heidenhain.de
